WiFi Bridge vs. Access Point: Understanding the Difference

This page explains what a WiFi bridge and an access point are, focusing on their role in wireless networking.

The primary function of a wireless bridge is to act as an interface between wired and wireless devices. Essentially, the wireless bridge picks up the signal from a wireless router and then transmits that signal to devices connected to it via Ethernet cables. A wireless bridge specifically used in a WiFi network is commonly called a WiFi bridge.

The main benefit of a WiFi bridge is that it extends the coverage area of your WiFi signal.

One example of a WiFi bridge is the Xtreme N® Duo from D-Link. Here are some of its key features:

• It supports IEEE 802.11 g, 11n, 802.3, and 802.3u standards.
• It has 4 LAN ports, allowing you to connect multiple wired devices.
• It includes a WPS (Wi-Fi Protected Setup) push button for easy pairing.
• It uses internal antennas.
• It features LEDs to indicate the status of power, bridge connection, access point mode, LAN connections, and WPS.
• It should have passed WiFi ®, FCC, and IC certifications.

Important Tip: When setting up your WiFi bridge, make sure to position it within the WiFi coverage area of your router and within a reasonable cable distance of the wired devices you want to connect.
