RF Transformer calculator

This page of converters and calculators section covers RF Transformer calculator. The most widely and most common core used for RF Transformer is toroid. A toroid is a circular doughnut shaped core usually made of a special type of powdered iron material.

To make RF transformer, copper wire is wound on the toroid to create both primary and secondary windings.

Input impedance to RF Transformer (input1) :

Output impedance of RF Transformer (input2) :

Ratio of Ns to Np (Output):


*Note: Enter values in INPUT boxes and Press CALCULATE button to check OUTPUTS.

EXAMPLE:
Input impedance = 5, output impedance = 50
Ratio of Np to Ns = 0.316
Hence Primary turns are 3.16 times more than the Secondary turns.


RF Transformer Equation

Following equation or formula is used for RF Transformer calculator.

RF Transformer equation for calculator
